Lay a Herringbone Floor With Quick-Step Laminate in 9 Steps for 40% Faster Fitting

Preparation: flat floor, centre axis, and A/B stacks

Quick-Step sells its Capture range as click-together herringbone, and the boxes contain two distinct plank types. The boards are marked A and B on the packaging and on the back. They are mirror images, with a left-hand and right-hand cut, and the click profile engages in only one direction. A plank picked from the wrong stack simply refuses to lock, which is how a first row can drift away from the 45-degree angle before the error becomes obvious.

Sort the room before any cutting starts. Put A planks in one stack and B planks in another, each within reach of the working position. A herringbone plank runs around 600 by 145 mm, so a 20 square metre room takes roughly 230 boards, around 115 of each type. Counting the stacks at the start shows whether the delivery is short and prevents the mid-job discovery that one side of the pattern has been used up.

A 4 mm dip over 2 metres will telegraph through 8 mm laminate as a hollow click underfoot, even when the chevrons line up properly. Herringbone has short planks and a dense joint count, so it exposes a bad screed more readily than a long straight board. Use a long level and a torch before the boxes are opened across the room.

Find the room’s longest sightline, usually the wall a visitor sees first, and snap a chalk line down the dead centre of the floor parallel to it. Herringbone reads as crooked from a doorway quickly, so the visible axis matters as much as the tape measure. Measure to the midpoint at both ends of the room, mark them, snap the line with a Tajima chalk reel, then check it with a 2 metre spirit level laid along the string.

Dry-lay the first chevron along that line before locking the boards. Set one A and one B into their 90-degree point, sitting astride the chalk line so the apex of each V touches it. This test shows where the pattern will meet the side walls. If a chevron point lands 30 mm from the skirting, shift the whole centre line sideways by half a plank width and snap again. Five minutes spent here removes a run of slivered perimeter cuts later.

Lay the underlay after the chalk line and dry run have settled the geometry. Quick-Step recommends its own Livyn underlay or a 2 mm to 3 mm closed-cell underlay for herringbone because diagonal joints concentrate point loads differently from straight planks. Tape the seams with aluminium tape, run the underlay 40 mm up the wall, and trim it flush once the floor is down. Untaped seams can separate as the foam moves, and that gap is a common source of squeaks within a season.

The 10 mm gap

Leave 10 mm clear of every wall, pipe, and door frame. Laminate moves with humidity, and a herringbone field locked tight against a radiator pipe can tent in July. Place spacers every 400 mm and remove them only after the skirting is ready to go back on.

Building outward from the spine

Start clicking from the centre line and work toward one wall, then return to complete the other half of the room. The first locked chevron anchors the whole floor, so check its angle with a speed square before adding the second pair. Quick-Step’s Uniclic profile wants the plank presented at roughly 25 degrees and then dropped flat. Fold it down with the heel of your hand near the joint; pressure applied from the far end can crack the locking lip and turn the board into scrap.

A tapping block is especially useful on herringbone because many taps land on a 45-degree edge. Use the Quick-Step branded block or any block with a profiled lip that grips the tongue without crushing it. A loose offcut used as a hammer pad can mark the decor layer. Keep a Wolfcraft pull bar nearby for the final planks against each wall, where a mallet swing has little space and the joint closes by hooking the bar over the plank end and tapping the bend in the bar itself.

The first three courses usually feel slow. Each angle is still being tested against the line, and the A/B rhythm has to be checked board by board. After eight chevrons are locked, the pattern becomes self-correcting in a practical sense: each new board has only one sensible position, and the hands settle into A, then B, then A again. The saving comes from removing repeated stops for sorting and angle checking.

Cut the perimeter planks after the field is laid. Measure each gap individually because walls in real houses rarely run perfectly parallel. Mark the cut on the decor side, score it with a Stanley knife along a straight edge, and finish it with a jigsaw fitted with a laminate-specific downcut blade so the teeth pull the splintering into the offcut. A standard upcut blade chips the visible face.

Last row, thresholds, and skirting

The last row against a wall usually arrives at a diagonal. Hold the plank over its final position, mark where it meets the wall at the near and far points of the chevron, join those marks, and cut along that line. Include the 10 mm expansion gap in the marks themselves, or the same board will need a second cut.

Doorways need a Quick-Step Incizo profile or an equivalent trim that bridges to the adjoining floor. The profile clips into an aluminium subrail screwed to the subfloor, with the subrail carrying every fixing so the laminate edge stays free underneath and the floor can still move. Screws driven through the laminate itself can create a hairline crack radiating from the doorway within months.

Refit the skirting after the floor is complete, pinning it to the wall so the 10 mm gap remains open below. A 16-gauge brad nailer into the wall studs holds the skirting while the laminate remains free to move. If the old skirting stays in place and lifting it would damage the wall, scotia or quadrant beading pinned to the skirting face covers the gap and moves with seasonal change.

A 4 by 5 metre room

Take a 4 m by 5 m bedroom, which is 20 square metres. At roughly 230 herringbone planks plus a 7 percent cutting allowance, the order becomes 250 boards. Quick-Step packs around 0.9 square metres per box, so 25 boxes cover the room with about a half-box spare. Underlay rolls cover 10 square metres each, so the same room needs two rolls plus one roll of aluminium tape.

Subfloor check and chalk line take about 45 minutes. Underlay and tape take about 30 minutes. The first eight chevrons, the slowest part, need close to an hour for 20 boards because every angle gets verified. The open field, about 180 boards, then runs at roughly 50 boards an hour once the A/B rhythm is set, which is around three and a half hours. Perimeter cutting and diagonal last-row marks take another 90 minutes because each piece is bespoke. Thresholds and skirting add around an hour.

Those blocks add up to about eight hours, comfortably one working day for one fitter who sorted the planks before starting. The same 20 square metre room can stretch toward a day and a half when A and B boards are dumped into one pile and the centre line is judged by eye. The 40 percent saving belongs to that difference between a pattern that starts correcting itself and a layout that keeps compounding small errors.

What the timeline does not settle is the room that fights the geometry from the start, where every wall runs slightly out of square and no half-plank shift of the centre line lands the chevron points cleanly on both sides at once.
